9. Use the arrow keys to highlight the Frame Format field near the
bottom of the screen.
10. Use the SPACE bar or BACKSPACE to step to the appropriate frame
format setting (NORMAL, TAGGED, or UNTAGGED) for the
selected Destination Port.
11. Use the arrow keys to highlight the Remap Errors field near the
bottom of the screen.
12. Use the SPACE bar to select either the ON or OFF option and press
ENTER. ON forces the source port to forward errored frames to the
destination port(s). OFF forces the errored frames to be dropped
before forwarding traffic.
13. Use the arrow keys to highlight the Status field.
14. Use the SPACE bar to select either the ADD or DEL option. Press
ENTER. This adds or deletes the selections for the Source Port,
Destination Port, Frame Format, and Redirect Errors made in steps 1
through 12 and also updates the screen.
If more than one port is being redirected, repeat steps 1
NOTE
through 14 for each additional setting. Then go to step 15 to
save all the new settings at once.
If an entry is to be changed, delete the entry, save the screen,
then recreate the entry with its new settings.
Any combination of port redirect instances (configured on the
Port Redirect Configuration screen) and/or VLAN redirect
instances (configured on the VLAN Redirect Configuration
screen) can be configured, up to 128 instances total per
module. A maximum of 640 instances can be configured on a
fully loaded (5 module) chassis. Up to 24 instances can be
configured as remote instances to other modules in the
chassis. Remote instances are instances that are mapped from
one module to another within the same chassis.
15. Use the arrow keys to highlight SAVE at the bottom of the screen.
Press ENTER. The message "SAVED OK" displays. This saves the
new settings and updates the Source Port and Module, and the
Destination Port and Module read-only fields.
