Chapter 1: Changes to Local Management Screens
To access the Redirect Configuration Menu screen from the Chassis Menu
screen, use the arrow keys to highlight the PORT REDIRECT menu
item and press ENTER. The Redirect Configuration Menu screen
displays.
Figure 1-5 Redirect Configuration Menu Screen (Chassis)
The following defines each selectable item of the Redirect Configuration
Menu screen:
PORT REDIRECT CONFIGURATION
Used to redirect traffic from a source switch port to a destination switch
port. The source and destination ports can be on different modules in the
chassis. For details, refer to
VLAN REDIRECT CONFIGURATION
Used to configure the module to direct traffic from a VLAN to a particular
switch port across modules in the chassis. For details, refer to
1-8
PORT REDIRECT CONFIGURATION
VLAN REDIRECT CONFIGURATION
EXIT
Section 1.5.
Local Management Supplement
RETURN
3026_94
Section 1.6.
