Cabletron Systems SmartSwitch 6E122 Supplement Manual page 33

Source
----------------------
Module
1
1
1
1
1
1
1
1
Src VLAN ID [ 2 ]
Src Module [ 1 ]
SAVE
Figure 1-7 VLAN Redirect Configuration Screen (Chassis)
The following definitions briefly explain each field of the VLAN Redirect
Configuration screen:
Source Module (Read-Only)
Shows which modules are currently set as source modules.
Source VLAN ID (Read-Only)
Shows the VLAN ID of the VLANs that are currently set as source
VLANs.
Destination Module (Read-Only)
Shows which modules are currently set as destination modules.
Destination Port (Read-Only)
Shows which ports are currently set as destination ports. Multiple
VLAN IDs may be assigned to a destination port.
Local Management Supplement
VLAN Redirect Configuration Screen (Chassis)
Destination
------------------------
VLAN ID Module
1 2
2 2
3 2
4 2
5 2
6 2
7 2
8 2
Dest Port [ 2 ]
Dest Module [ 1 ]
PREVIOUS
Frame Format
--------------------
Port
RECEIVED
1
TAGGED
2
UNTAGGED
3
RECEIVED
4
RECEIVED
5
RECEIVED
6
RECEIVED
7
RECEIVED
8
Frame Format [UNTAGGED]
Redirect Errors UNSUPPORTED
NEXT
Remap Errors
--------------------
––
––
––
––
––
––
––
––
Status [ADD]
RETURN
RETURN
EXIT
3026_105
1-15
