Cabletron Systems SmartSwitch 6E122 Supplement Manual page 102

Chapter 3: LM Security Screens for 6H123-50 and 6H133-37
NETWORK# (Read-only)
Indicates the network on the connector selected in the CONNECTOR
field. Table 3-2
Ports on the module.
6H123-50
CONN 1 = Network 1, 10 Mbps
Network 2, 100 Mbps
CONN 2 = Network 3, 10 Mbps
Network 4, 100 Mbps
CONN 3 = Network 5, 10 Mbps
Network 6, 100 Mbps
CONN 3 = Network 7, 10 Mbps
Network 8, 100 Mbps
LINK STAT. (Read-only)
Displays the Link status (Link or No Link) of the port.
CURRENT OPER. MODE (Read-only)
Displays the current operating mode of the port.
DESIRED OPER. MODE (Selectable)
Steps through the following operating mode options: Auto-Neg (Auto
Negotiation), 10Base-T, and 100Base-TX.
• When Auto-Neg. is selected, the port Auto-Negotiates with the module
to which it is attached to determine its Operating Mode (10 Mbps or
100 Mbps).
• When 10Base-T is selected, the port is forced to operate in standard
Ethernet mode (10 Mbps) only.
• When 100Base-TX is selected, the port is forced to operate in Fast
Ethernet mode (100 Mbps) only.
To set the port operating mode, refer to
3-4
shows the association between the CONN and Network
Table 3-2 CONN/Network Organization
6H133-37
CONN 1 = Network 1, 10 Mbps
Network 2, 100 Mbps
CONN 2 = Network 3, 10 Mbps
Network 4, 100 Mbps
CONN 3 = Network 5, 10 Mbps
Network 6, 100 Mbps
HSIM = 7
Section 3.2.1.
Local Management Supplement
