Chapter 1: Changes to Local Management Screens
Frame Format (Read-Only)
Displays the current frame format setting: RECEIVED, TAGGED or
UNTAGGED. The default is RECEIVED.
• RECEIVED – Frames are redirected in the format in which they were
received by the module.
• TAGGED – Frames are transmitted on the destination port with a
VLAN tag inserted according to the frame classification.
• UNTAGGED – Frames are transmitted on the destination port without
a VLAN tag regardless of the format of the received frame.
Refer
NOTE
fields.
Remap Errors
Unsupported (only valid frames can be classified into a VLAN).
Src VLAN ID [ n ] (Modifiable)
Used to enter the VLAN ID of the VLAN that is to be changed to a source
VLAN. If a VLAN is currently being redirected, it will not display as a
selectable VLAN.
Src Module [ n ] (Selectable)
Used to select the module [n] that is to be changed to a source module.
Dest Port [ n ] (Selectable)
Used to select the port [n] that is to be changed to a destination port. If a
port is currently being redirected, it will not display as a selectable port.
Dest Module [ n ] (Selectable)
Used to select the module [n] that is to be changed to a destination
module.
Frame Format (Selectable)
Used to select the frame format for the transmission of redirected frames
on the destination port. RECEIVED, TAGGED, or UNTAGGED may be
selected. Refer to the previously described read-only Frame Format field
for details about each format. The default setting is RECEIVED.
1-16
Section 1.6.1 to change the settings on the following
