Chapter 1: Changes to Local Management Screens
Reboot After Download (Modifiable when user chooses RUNTIME)
This field notifies the user that the SmartSwitch will reboot after the
download is complete. If a RUNTIME Download is performed this field
toggles between YES and NO. If YES is selected, the module reboots
after the download is completed. If NO is selected the module will
continue using the existing firmware image. The module stores the new
firmware image in FLASH memory. When the module or 6C105 chassis
is reset, the module will boot from FLASH memory using the new image.
TFTP Gateway IP Addr (Selectable)
This field shows the IP address of the TFTP gateway server defined in the
General Configuration screen.
Last Image Server IP (Read-only)
This field shows the IP address of the server used for the previous FLASH
Download.
Last Image File Name (Read-only)
This field shows the complete path and file name of the last image
downloaded to FLASH.
If TFTP or RUNTIME is selected as the download method
NOTE
(Figure
Download Server IP (Selectable)
The IP address of the TFTP server to be used for the FLASH download is
entered in this field.
Download File Name (Selectable)
The complete TFTP server path and file name of the new image is entered
in this field.
1.9.1

Image File Download Using TFTP

Set the module to download to FLASH using TFTP as follows:
1. Use the arrow keys to highlight the Download Method field.
2. Use the SPACE bar to select TFTP.
1-24
1-10), the following two additional fields display.
