Chapter 1: Changes to Local Management Screens
1.2

ACCESSING LOCAL MANAGEMENT

Access to Local Management (LM) is controlled through the Password
screen.
1.2.1

Navigating Local Management Screens

The Local Management application consists of a series of menu screens.
Navigate through Local Management by selecting items from the menu
screens.
The SmartSwitch supports three modes of switch operation. The
switching modes are as follows:
• 802.1D Switching (traditional switching)
• 802.1Q Switching (802.1Q VLANs)
• SecureFast VLAN (Cabletron Systems SecureFast switching). A
separate image is required for this operation.
Refer to the Release Notes shipped with the product to verify
NOTE
which screens are supported in each of the available switching
modes.
Depending on the Operational Mode set for the module, the hierarchy of
the Local Management screens differs as shown in
Figure 1-2. Refer to the appropriate figure that relates to the Operational
Mode set for the module to see the applicable Local Management screen
hierarchy.
The areas that changed in the hierarchy are highlighted as
NOTE
shown in
covered in this document. These screens may have been
added, changed, or have changed location in the
hierarchy.
1-2
Figure 1-1 and Figure
Figure 1-1
1-2. The screens involved are
Local Management Supplement
and
