USB Deviceserver User Manual Linux
Parameters
Subnet mask
Gateway
Assigning an IPv4 Network Configuration using the SEH UTN Manager
 The SEH UTN Manager (complete version) is installed on the client  11.
 The UTN server is shown in the selection list  38.
1. Start the SEH UTN Manager.
2. In the selection list, select the UTN server.
3. In the menu bar, select UTN Server–Set IP Address.
The Set IP Address dialog appears.
4. Enter the relevant TCP/IP parameters.
5. Click OK.
 The settings will be saved.
Determining the IPv4 Address using the SEH UTN Manager and Assigning an IPv4 Network Configuration
The SEH UTN Manager searches the network for connected UTN servers.
 The SEH UTN Manager (complete version) is installed on the client  11.
1. Start the SEH UTN Manager.
2. Confirm the note dialog Your Selection List seems to be empty with Yes.
If no note dialog is available and the main dialog appears, select Selection List–Edit in the menu bar.
The Edit Selection List dialog appears.
3. In the network list, select the UTN server.
If you are using several UTN servers of the same model, you can identify a specific de-
vice by its default name
4. In the shortcut menu, select Set IP Address.
The Set IP Address dialog appears.
5. Enter the relevant TCP/IP parameters.
6. Click OK.
 The settings will be saved.
Description
Subnet mask of the UTN server.
Subnet masks are used to logically partition big networks into subnetworks. If
you are using the UTN server in a subnetwork, it requires the subnet mask of
the subnetwork.
IP address of the network's standard gateway which the UTN server uses.
With a gateway, you can address IP addresses from other networks.
( 20) or the connected USB devices.
