Technical Features - Pavone Systems DAT11 Technical Manual

Power supply
Max. absorption
Isolation
Operating temperature
Storage temperature
Weight display
Led
Keyboards
Overall dimensions
Installation
Material
Connections
Load cells Input
Load cell excitation
Linearity
Temperature drift
Internal resolution
Measuring range
Digital filter
Number of decimals weight
Calibration of zero and full scale
Check of load cell cable interruption
Logic outputs (DAT11/A)
Logic Inputs (DAT11/A)
Serial ports
Baud rate
Maximum cable length
Optional Fieldbus
Ethernet Protocols
Communication mode
Buffer size
Connection Timeout
Link Timeout (no cable connection)
Analog output (DAT 11/A)
Resolution
Calibration
Linearity
Temperature drift
Microcontrollor
Memoria dati
In compliance with the standards
Page 4

TECHNICAL FEATURES

24 Vdc ±10% protected against reverse polarity.
Protection with resettable fuse.
3W
Class II
-10°C ÷ +50°C (max. humidity 85% non-condensing)
-20°C ÷ +60°C
Numerical 6 red led digits and 7 segments (h 7 mm)
2 LEDs of 3 mm
3 mechanical keys (behind the red front door)
112 x 119 x 23 mm (l x h x w) including term. boards.
Brackets for DIN section or OMEGA bar
Self-extinguishing Blend PC/ABS
Removable screws terminal boards, pitch 5.08 mm
max. 4 of 350
4 Vdc
<0.01% of the full scale
<0.001% of the full scale / °C
24 bit
-7,6 ÷ +7,6 mV/V
To be selected from 0.1 Hz to 250 Hz
0 ÷ 4 decimal places
From the buttons.
Always present
2 relay outputs with No contact(0,1A, 24 Vdc/Vca)
No. 2 opto-isolated
RS232 half duplex
RS485 half duplex
USB C Device
2400 ÷ 115200 baud
15m (RS232) and 1000m (RS485)
PROFIBUS DP V1, PROFINET, CANOPEN, ETHERNET
IP, ETHERCAT, ETHERNET
TCP, Modbus/TCP, UDP, IP, ICMP, ARP. Web server
integrated
TCP server
256 byte
Min 30 seconds - Max 90 seconds
30 seconds
Voltage: ± 10 V / ± 5 V (min. 10 K )
Current: 0÷20 mA / 4÷20 mA (max 300
16 bits
Digital from keys
0.03% of the full scale
0.002% of the full scale / °C
ARM Cortex M0+ to 32 bit, 256KB Flash
reprogrammable on-board by USB..
32 Kbytes expandable up to 1024 Kbytes
EN61000-6-2, EN61000-6-3 EN61326-1:2013 for EMC
EN61010-1 for Electrical Safety
in parallel (or 8 cells of 700 ).
)
