Technical Features - Pavone Systems DAT 200 Technical Manual

Power supply
Max. absorption
Isolation
Operating temperature
Storage temperature
Weight display
Led
Keyboards
Overall dimensions
Installation
Material
Connections
Input of the load cells with following features
Load cell excitation
Linearity
Temperature drift
Internal resolution
Measuring range
Digital filter
Number of decimals weight
Calibration of zero and full scale
Check of load cell cable interruption
Serial ports
Baud rate
Maximum cable length
Fieldbus
Connection
Buffer size
In compliance with the standards
Page 4

TECHNICAL FEATURES

24 Vdc ±10% protected against reverse polarity.
Protection with resettable fuse.
2W
Class II
-10°C ÷ +50°C (max. humidity 85% non-condensing)
-20°C ÷ +60°C
Numerical with 5 red led digits and 7 segments (h 7
mm)
2 LEDs of 3 mm
3 mechanical keys (behind the red front door)
112 x 119 x 35 mm (l x h x w), including terminal
boards.
Brackets for DIN section or OMEGA bar
Self-extinguishing Blend PC/ABS
Removable terminal boards with screws, pitch 5.08
mm
max. 4 of 350 Ω in parallel (or 8 cells of 700 Ω).
4 Vdc
<0.01% of the full scale
<0.001% of the full scale / °C
24 bit
-3.9 ÷ +3.9 mV/V
To be selected from 0.2 Hz to 25 Hz
0 ÷ 4 decimal places
From the buttons.
Always present
RS232 half duplex
2400 ÷ 115200 baud
15m
PROFINET / ETHERNET IP
RJ45 connector
128 byte IN - 128 byte OUT
EN61000-6-2, EN61000-6-3, EN61326-1 for EMC
EN61010-1 for Electrical Safety
UL: FILE NO E474362
