Pavone Systems DAT11 Technical Manual page 66

1409 Delay output 1
1410 Output mode 2—F unction
1411 Output mode 2— Logic
1412 Output mode 2— Polarity
1413 Output mode 2 — Stability
1414 Hysteresis output 2
1415 Timing output 2
1416 Delay output 2
1501 Analogue Tare (MSB
1502 Analogue Tare (LSB)
1503 Analogue Full Scale (MSB
1504 Analogue Full Scale (LSB)
1505 Analogue Output Mode
1506 Analogue Output Range
1507 Regulation of analogue zero
1508 Regulation of analogue full scale
2000 Monitor register
2100 Monitor register
(*) These registers can only be modified in FREE mode or if in METRIC mode with a calibration
bridge enabled.
TABLE A - REGISTER STATUS CODING
BIT 15
Description Setup (***)
BIT 7
Not
Description
calibrated
TABLE B - KEYPAD LOCK CODING
BIT 15÷4
Not used
Description
ATTENTION: the bits from 15 to 4 are not managed and are always equal to 0.
TABLE C - INPUTS/OUTPUTS CODING
BIT 15÷2
Description Not used IN/OUT 2 Active IN/OUT 1 Active
ATTENTION: the bits from 15 to 4 are not managed and are always equal to 0.
R/W Valore INT.
R/W See correspondence on page 45
R/W See correspondence on page 46
R/W See correspondence on page 46
R/W See correspondence on page 46
R/W INT. value
R/W INT. value
R/W INT. value
R/W INT. value - Most significant word
R/W INT. value - Less significant word
R/W INT. value - Most significant word
R/W INT. value - Less significant word
R/W See correspondence on page 32
R/W See correspondence on page 32
INT. value Analogue output zero points, to end the regulation
R/W procedure it is necessary to send the data storage command to
the permanent memory in the Command Register.
INT. value Analogue output full scale points, to end the regulation
R/W procedure it is necessary to send the data storage command to
the permanent memory in the command register.
The programmed value is automatically copied in the Monitor
W
Register R (2100).
R
14 13
Weight
Output 2
difference
6 5
Weight
Over-load
error
3 2
SET Key FUN Key
1
12 11
Output 1 Input 2
4 3
Under- Tare
load entered
1 0
0 Key PRG Key
0
10 9
Run
Input 1
Backup function
2 1
Zero Stable
band weight
Page 64
8
Hold
0
Zero
centre
