Pavone Systems DAT11 Technical Manual page 27

TEST MENU
MENU MESSAGE
S1GnAL
H1 rES.
PSuppL.
NENory
tESt
1n oUt.
rS 232
rS 485
oUt. . An
SETUP MENU
MENU SUB MENU
CAL1br.
AnALoG
CoN. P or. .
1n-oUt.
PArAN
SEtuP
F1LtEr
FUnCt
uPL. d ow
accEss
ali. N EN
(*) These menu items are displayed only when operating in FREE mode or if accessed using the
password of authorised personnel (if operating in METRIC mode).
(***) This menu items are only displayed when operating in METRIC mode.
On exiting the setup menu, if changes were made to the parameters, the message StorE, is displayed
which is confirmed with ENTER
NAME
Cell signal
Resolution x10
Power supply voltage
Test of the memory
(Only with configured
memory)
I/O test
Test RS232
Test RS485
Analogue output test
Calibration Settings (*)
Analog output settings (Only with analog output configured)
Serial ports and fieldbus settings
Logic Output and Input settings
Weighing meteorological parameter settings
Filter Settings
Functional Features settings
Upload/Download function of saved setup data
Showing the last 5 accesses of the Authorized Staff (***)
Aliby memory consultation (***)
DESCRIPTION
Display of the signal in mV/V in input to the
instrument
Display of the weight with a resolution 10
times greater than that set
Display of the supply voltage measured by
the instrument
Automatic operation test of the additional
memory
I/O test with simultaneous display of inputs
and outputs (See specific description)
Transmission and receipt test (See specific
description)
Transmission and receipt test (See specific
description)
Test procedure with manual activation of the
output value (See specific description)
NAME
TYPE
Vis.
Vis.
Vis.
Test.
Test.
Test.
Test.
Test.
Page 25
