The following table lists the registers of the output area (written by the master and acquired by the
instrument), common to all PROFIBUS, PROFINET, ETHERCAT, ETHERNET / IP Fieldbuses.
The registers are 16 bit in size. The registers written by the master in the output area, are read by the
instrument at a fixed frequency of 125 Hz. (80 Hz in case of PROFIBUS)
The size of the output area configured in the master fieldbus must match the size configured in the
instrument.
OUTPUT DATA AREA
Register
Byte OUTPUT AREA REGISTER
address
1-2 0 Command Register
3-4 1 Data Register (MSB)
5-6 2 Data Register (LSB)
7-8 3 Monitor register
9-10 4 Set-Point 1 (MSB)
11-12 5 Set-Point 1 (LSB)
13-14 6 Set-Point 2 (MSB)
15-16 7 Set-Point 2 (LSB)
17-18 8 Capacity of load cells (MSB)
19-20 9 Capacity of load cells (LSB)
21-22 10 Sensitivity of load cells
23-24 11 Weight division value
25-26 12 Decimals
27-28 13 Fixed Tare (MSB)
29-30 14 Fixed Tare (LSB)
31-32 15 Stand-by function
33-34 16 Keypad Lock function
35-36 17 Password function
37-38 18 Peak function
39-40 19 Data-Logger function
41-42 20 Data-Logger Trigger
43-44 21 Data-Logger function
45-46 22 Filter factor
47-48 23 Output rate ADC
49-50 24 Number of readings on average
51-52 25 Monotony Time
53-54 26 Oscillations Time
55-56 27 Oscillations Range
57-58 28 Full Scale (MSB)
59-60 29 Full Scale (LSB)
61-62 30 Weight stability
63-64 31 Auto zero when switching on (MSB) INT. value - Most significant word
65-66 32 Auto zero when switching on (LSB)
67-68 33 Zero tracking
69-70 34 Resettable Divisions (key >0<)
71-72 35 Input 1 function
73-74 36 Input 2 function
75-76 37 Input 1 mode —Function
Page 69
Note
See relevant table.
INT. value - Most significant word (See Table)
INT. value - Least significant word (See Table)
This value corresponds to the same register in the input area.
INT. value - Most significant word
INT. value - Less significant word
INT. value - Most significant word
INT. value - Less significant word
INT. value - Most significant word
INT. value - Less significant word
INT. value
See relevant table.
See relevant table.
INT. value - Most significant word
INT. value - Less significant word
INT. value
See relevant table.
INT. value
See correspondence on page 51
See correspondence on page 52
See correspondence on page 52
See correspondence on page 52
See correspondence on page 49
See correspondence on page 49
INT. value
INT. value
INT. value
INT. value
INT. value - Most significant word
INT. value - Less significant word
See correspondence on page 47
INT. value - Less significant word
See correspondence on page 48
INT. value
See correspondence on page 44
See correspondence on page 44
See correspondence on page 44
