Pavone Systems DAT11 Technical Manual page 70

71-72 35 Monotony Time
73-74 36 Oscillations Time
75-76 37 Oscillations Range
77-78 38 Full Scale (MSB)
79-80 39 Full Scale (LSB)
81-82 40 Weight stability
Auto zero when switching on
83-84 41
(MSB)
Auto zero when switching on
85-86 42
(LSB)
87-88 43 Zero tracking
89-90 44 Input 1 function
91-92 45 Input 2 function
93-94 46 Input 1 mode —Function
95-96 47 Input 1 mode —Logic
97-98 48 Input 1 mode —Polarity
99-100 49 Input 1 mode —Stability
101-102 50 Hysteresis input 1
103-104 51 Timing input 1
105-106 52 Delay input 1
107-108 53 Input 2 mode —Function
109-110 54 Input 2 mode —Logic
111-112 55 Input 2 mode —Polarity
113-114 56 Input 2 mode —Stability
115-116 57 Hysteresis input 2
117-118 58 Timing input 2
119-120 59 Delay input 2
121-122 60 Analogue Fixed Tare (MSB)
123-124 61 Analogue Fixed Tare (LSB)
125-126 62 Analogue Full Scale (MSB)
127-128 63 Analogue Full Scale (LSB)
READING EXAMPLE
To read the gross weight on the DAT 11 it is needed to read the addresses from 3 to 6 of the Input Area.
To read the net weight is needed to read the addresses from 7 to 10 of the Input Area.
When the display shows the gross weight value of 12351 in the corresponding bytes there will be:
Byte 3
Hex 00
INT. value
INT. value
INT. value
INT. value - Most significant word
INT. value - Less significant word
See correspondence on page 46
INT. value - Most significant word
INT. value - Less significant word
See correspondence on page 47
See correspondence on page 43
See correspondence on page 43
See correspondence on page 43
See correspondence on page 43
See correspondence on page 44
See correspondence on page 44
INT. value
INT. value
INT. value
See correspondence on page 44
See correspondence on page 45
See correspondence on page 45
See correspondence on page 45
INT. value
INT. value
INT. value
INT. value - Most significant word
INT. value - Less significant word
INT. value - Most significant word
INT. value - Less significant word
Byte 4 Byte 5
00 30
Byte 6
3F
Page 68
