The second menu is that of tEst concerning procedures for functional testing of the instrument.
The third is that of SEtup which allows you to program the parameters which determine the operation
of the instrument
To access the setup menu, press the PRG key and then the SET key and hold them down simultaneously
for 3 seconds or press and hold the PRG key for at least 6 seconds .
Access by confirming your choice with the PRG key.
MESSAGE
Information
1nFo
Test
tEst

Setup

SEtuP
INFO MENU
MENU MESSAGE
Cod. FN
rEL. FN
F. S CALE
F. bUS
Addr.
1nFo
1P
SubnEt.
oUt. . An
NENory
In the case of PROFINET field bus: the parameters IP address and Subnet Mask are programmable by
PLC and are updated in this menu only when the instrument is switched on. Following a change in these
parameters from the PLC, the instrument must be switched off and on again to display the correct value.
It is important to remember that even if you set the parameters IP address and subnet mask in Temporary
mode, these parameters are not automatically updated in the instrument. Moreover, when the instrument
is switched off and then on again, these parameters will all be set to 0.0.0.0.
Page 24
NAME
Parameter menu can be viewed for identification of the instrument
and its configuration.
Menu of test procedures for operation of the instrument hardware.
Menu of programmable parameters which determine the opera-
tion of the instrument
NAME
Firmware code
Firmware revision
Full scale of the
instrument
Fieldbus present
Fieldbus address
Fieldbus IP address
Subnet Mask
Fieldbus
Analog Output
Configuration
Optional Memory
Configuration
DESCRIPTION
DESCRIPTION
Indication of installed Firmware code
Indication of revision of the Firmware installed
Indicates the full scale set
Indicates the type of Fieldbus configured
Indicates the Fieldbus address set. This
menu item is displayed only in the RS485
configurations.
Indicates the IP Fieldbus address set. This
menu item is displayed only in the ETHERNET,
PROFINET and ETHERNET/IP configurations.
Indication of the subnet mask Fieldbus set. This
menu item is displayed only in the ETHERNET,
PROFINET and ETHERNET/IP configurations.
Indicates the presence and type of analogue
output (Not present - Unipolar - Bipolar)
Indicates the presence and type of memory
(None - Alibi memory - SD card)
TYPE
Vis.
Vis.
Vis.
Vis.
Vis.
Vis.
Vis.
Vis.
Vis.
