When the instrument is switched ON, a display test is run followed by the identifica-
P33301
tion code and then the version of the software, in that order. These codes are to be
cited when requesting assistance
When is not in progress a programming procedure, the display shows the weight measured in kilograms.
Under certain conditions, the following messages are reported:
NOTIFICATION OF ERRORS
In operating mode, the following error codes may appear on the display.
P <picco>
Display of peak value.
Communication with "Optimation" PC utility software.
rENotE
Overload. The load applied to the load cells exceeds by over 9 divisions the maximum
capacity of the weighing system.
Underload. The weight displayed is less than -99999.
______
Signal that the load cells are absent or outside of the measuring range mV/V.
O-L
Calibration weight not performed)
No CAL
Fieldbus network disconnected
No CoN
Fieldbus interface absent or not working.
E-F. b uS
DISPLAY INFO
Fixed message
Flashing message, alternating with the weight measured.
Page 17
