"Reset" cursor must be push when the settings are changed. If not press "Reset",
parameter changes back to original value when move to another display. When press the
"Reset" DigiPackⅡrestarting automatically, please do not apply hydraulic pressure, when
press "Reset".
MACHINE SETTING (F4+Set) FUNCTION
1-7-3.
Profile interpolation
Language
Back light (min)
LCD
Memory
Machine Type
Servovalve type
Valve current
Open command
Core sensor
Output mode select
SSI ratio
SSI data code type
SSI bits
SSI clock
SSI position offset
Pulse out rate 1
Pulse out rate 2
Pulse out polarity
Marked as (*) is initial setting with new DigiPackⅡshipped.
© MOOG 2010
This document is subject to MOOG INTELLECTUAL AND PROPRIETARY INFORMATION LEGEND . The details are on page II.
Sets a interpolation (*)Straight or Spline on the profile disply (F1)
Language – ((*)English/ Chinese / Japanese) Sets the language used on the LCD Display
Sets the timer of screen saver. 5, 10, (*)30 min or non screen saver.
Adjust the screen brightness. Knob CCW : dark, Knob CW : bright
Select actual feedback line indicated on profile display. (*)ON : Show, OFF : Not Show
Machine type – Accumulator or (*)Continuous
Servovalve type – EFB or (*)MFB
Valve current of MFB type – 10, 20, 50 or (*)100 mA
Cursor move admission to Open command on Monitor display (F4) Enable or (*)Disable
Core Sensor type – (*)DCDT or SSI
Select control target. (*)EFB/MFB: Servovalve, Pulse: Pulse train Servo motor drive.
Sensor parameter of SSI type.
Ratio (*)1.0
Code type (*)Gray
Bits (*)12+12
Clock (*)160
Offset (*)0.00
* When press "zero", SSI position offset automatically updated, and set current posi-
tion to "0"V feedback. (This change also required press Reset )
Output mode select to "Pulse", needs to set this value. (*)1
If
This value is total distance of count set with Pulse out rate 2
Ex) rate1=10um, rate2=5puls, -> 5puls=10um.
Output mode select to "Pulse", needs to set this value. (*)1
If
See Pulse out rate 1
Set polarity of motion direction for Pulse train servo motor drive (*)Normal
