DigiPackⅡ Manual, Installation and Maintenance
1-3. DigiPackⅡ SPECIFICATION
Model Number:
Function:
Application:
Profile Points:
Tooling Type:
Tooling Position Control:
Tooling Position Monitor:
Programming Inputs:
Display:
Memory:
Marker:
Other Functions:
Output to Servovalve:
Servovalve Monitor:
I/O for Accumulator:
I/O for Tooling Position:
Common External Input:
24 VDC External Outputs:
Communication:
Power Requirements:
Temperature/Humidity:
IP rating
Dimensions:
Weight:
© MOOG 2010
This document is subject to MOOG INTELLECTUAL AND PROPRIETARY INFORMATION LEGEND . The details are on page II.
J141-214A DigiPackⅡ.
100 Point Single Head Blow Molding Parison Programmer.
Accumulator Based or Continuous Extrusion Blow Molding Machines
may be selected.
100 points. And Straight or Spline interpolation can be selected.
Divergent or convergent die gap tooling types can be selected.
Digital closed loop servo system with a 0.5m sec update time.
From Tooling Position Actuator's DCDT ± 10 VDC.
From Accumulator Potentiometer 0 to 10 VDC FS.
By entry knob and front panel switches.
Color Display (LCD). 480(W) x 640 (H) pixels.
English/Japanese/Chinese language selected by Parameter at Setup
screen.
100 program profile patterns can be stored in a Flash RAM. And able
to saved in to SD card. *SD card supported standard type and up to
32GByte (SDHC) data size available.
A marker output signal can be set maximum 10 program point.
Shot Size, Delay, Cushion (for accumulator machines only), die gap,
data saving, profile curve adjustment (Weight and Range H/L), ad-
justment of the tooling actuator stroke and the accumulator position
transducer, battery backup for the system timer.
MFB type: ± 10, 20, 50, 100 mA or EFB type: ± 10 VDC
± 100% Spool Stroke equals 4-20mA
0 to 10 VDC transducer output and 10 V DC transducer excitation.
± 10 VDC DCDT output and ± 10 V DC DCDT excitation.
Photo Coupler Isolated
Customer Supplied 15 to 24 Vdc @ 10 mA /Channel
Photo MOS Relay
Customer Supplied 15 to 24 Vdc @
100mA /Channel Max.
End of Extrusion/Filling Relay Contacts:
250Vac @ 1 A/channel MAX.
Data transfer with host computer by RS422 and Ethernet
24 VDC 0.5A min (MAX 3.0A depend on Servovalve Power required)
No ripple requirement : Max +-10 %
0 to 45ºC within 95% relative humidity
Front side = IP20, Rear side = IP30
288 (W) x 240 (H) x 80 (D) mm
3.2 kg
7
MRJ04410
