USE OF "Open command" MAY RESULT IN DAMAGE TO THE TOOLING.
When the servovalve input is equal to any value other than those in the Zero range, servovalve oil flow will
cause the tooling cylinder to move. The tooling actuator will stop only when the servovalve input current is
within a very narrow band in the Zero current range. If the tooling actuator stops due to contact with the
die and mandrel, very high forces may be exerted on the tooling, possibly causing damage. It is highly
recommended that the hydraulic pressure be reduced to a low value to prevent possible damage.
To prevent inadvertent damage, setting the Open command to "Disable" in Machine setup display (F4+Set)
will disable this function.

F5: Data Display Mode

2-4-6.

Figure 2-27 Data Display Screen A

Mode is displayed by pushing the F5 Key
Display
Available when manufacturing containers.
Function
To display the conditions, parameters and profile data for the container currently being made. Press set to
see next page one by one.
© MOOG 2010
This document is subject to MOOG INTELLECTUAL AND PROPRIETARY INFORMATION LEGEND . The details are on page II.

Figure 2-28 Data Display Screen B

65

Figure 2-29 Data Display Screen C

MRJ04410
