F3: File Mode
2-4-4.
Mode is obtained by pressing the F3 Key.
Display
Available when manufacturing containers.
Function
This mode combines the profile, marker data and setup files
and stores them in a Flash RAM or SD card for future use.
To Flash RAM 100 files can be stored, and SD card can be
saved data depend on the size of SD card. The data stored
with identifying name of up to 32 characters, date and time.
Commands
When F3: File Mode is selected a choice Load, Load SD,
Save or Save SD, is displayed (
Save or Save SD can be selected, using the Entry Knob and
Set.
When the Save or Load to/from SD card, SD
card needs to insert SD card slot. If SD card
is not in slot, below message occurred and can
not continue file management.
"SD card is not insert to slot or format is not
Note that if LOAD or Load SD is selected, the current
container data file will be automatically overwritten. If the
current container data file is to be stored, SAVE must be
selected first.
Save or Save SD
Save or Save SD combines the profile data, function item
data and point markers in one file and stores this file in the
Flash RAM or SD card.
Use the Entry Knob to select Save or Save SD and press
Figure 2-18
the Set Key. (
The prompt 'Please edit file name Yes/No" is displayed.
Figure 2-18
(
)
If you select "YES: then go to
If you select "NO" then go to
© MOOG 2010
This document is subject to MOOG INTELLECTUAL AND PROPRIETARY INFORMATION LEGEND . The details are on page II.
Figure 2-17
). Load, Load SD,
correct"
)
Page 62.
Page 61.
Figure 2-17 F3: File Mode Selection Screen
Figure 2-18 Select SAVE
