Silencer

GENERAL

• The BDP-Q2-50-10, BDP-Q2-20-10 controllers are 2-quadrant speed controllers for electronically
commutating three-phase brushless motors with Hall sensors, which are arranged offset at 120
electrical degrees.
• The speed of the motor is preset by means of either an internal or an external potentiometer.
• The maximum constant current can be adjusted via an on-board potentiometer.
• The Direction of rotation of the motor can be preset by means of the Direction control input.
The controller output stage can be activated and deactivated by means of the Disable control input.
• The controller is safeguarded against heat overload by means of an internal thermal cutoff.
• The controller output stage has been constructed using POWER-MOSFET technology, resulting in very
high efficiency.
For technical application assistance: 800-577-8685 ext. 3539 • +1-828-837-5115
1995 NC HWY 141, Murphy, NC 28906-6864 • +1-828-837-5115 • Fax +1-828-837-0846
Moog Components Group
Series Brushless Controllers
®
2-quadrant speed controller for brushless motors
Moog Components Group
www.moog.com/components • email: mcg@moog.com
www.moog.com/components
BDP-Q2-50-10 , BDP-Q2-20-10
Instruction Manual
1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Silencer series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Moog Silencer series

  • Page 1 • The controller output stage has been constructed using POWER-MOSFET technology, resulting in very high efficiency. For technical application assistance: 800-577-8685 ext. 3539 • +1-828-837-5115 Moog Components Group 1995 NC HWY 141, Murphy, NC 28906-6864 • +1-828-837-5115 • Fax +1-828-837-0846 www.moog.com/components • email: mcg@moog.com Moog Components Group • www.moog.com/components...
  • Page 2 If the controller is brought from a cold environment into the operating environment, there can be condensation. Wait until the controller has reached the ambient temperature of the operating environment, and is absolutely dry before it is put into operation. For technical application assistance: 800-577-8685 ext. 3539 • +1-828-837-5115 Moog Components Group • www.moog.com/components...
  • Page 3 Motor speed may be controlled via one of the following three methods (see page 4 and 5 for detail instructions): 1. On-Board Speed Potentiometer 2. External Speed Potentiometer – (Recommend 10k – 10 Turn Precision Potentiometer) 3. External Control Voltage For technical application assistance: 800-577-8685 ext. 3539 • +1-828-837-5115 Moog Components Group • www.moog.com/components...
  • Page 4 H. Motor speed may now be varied by using the External Speed Potentiometer. Figure 1 Connection Diagram for External Speed Potentiometer For technical application assistance: 800-577-8685 ext. 3539 • +1-828-837-5115 Moog Components Group • www.moog.com/components...
  • Page 5 6. After completion of step #5, speed control is now active. 7. Set the maximum current via the on-board speed potentiometer (current). For technical application assistance: 800-577-8685 ext. 3539 • +1-828-837-5115 Specifications and information are subject to change without prior notice. © 2014 Moog Inc. MS3125, rev. 1 11/16 Moog Components Group •...
