Silencer
GENERAL
• The BDO-Q2-40-05 controller is a 2-quadrant speed controller for electronically commutating three-phase
brushless motors with Hall sensors which are offset at 120 electrical degrees.
• The speed of the motor is set by either an internal or an external potentiometer.
• The maximum constant current can be adjusted via an on-board potentiometer.
• The direction of rotation of the motor can be preset by the Direction control input. The controller output stage
can be activated and deactivated by the Brake control input and the Disable control input.
• The controller is safeguarded against heat overload by an internal thermal cutoff.
• The controller output stage has been constructed using POWER-MOSFET technology, resulting in very high
efficiency. With a maximum constant current of 5 A, the motor voltage is reduced by a maximum 4 V.
For technical application assistance: 800-577-8685 ext. 3539 • +1-828-837-5115
1995 NC HWY 141, Murphy, NC 28906-6864 • +1-828-837-5115 • Fax +1-828-837-0846
Moog Components Group
•
Series Brushless Controllers
®
2-quadrant speed controller for brushless motors
Moog Components Group
www.moog.com/components • email: mcg@moog.com
www.moog.com/components
BDO-Q2-40-05 (40 V, 5 A)
Instruction Manual
1
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Moog Silencer Series
Summary of Contents for Moog Silencer Series
- Page 1 • The controller output stage has been constructed using POWER-MOSFET technology, resulting in very high efficiency. With a maximum constant current of 5 A, the motor voltage is reduced by a maximum 4 V. For technical application assistance: 800-577-8685 ext. 3539 • +1-828-837-5115 Moog Components Group 1995 NC HWY 141, Murphy, NC 28906-6864 • +1-828-837-5115 • Fax +1-828-837-0846 www.moog.com/components • email: mcg@moog.com Moog Components Group • www.moog.com/components...
- Page 2 Unauthorized opening and improper repairs will put the user in danger and will void the product warranty. If the BDO-Q2-40-05 controller is brought from a cold environment into the operating environment, there can be condensation. Wait until the controller has reached the ambient temperature of the operating environment, and is absolutely dry before it is put into operation. For technical application assistance: 800-577-8685 ext. 3539 • +1-828-837-5115 Moog Components Group • www.moog.com/components...
- Page 3 Motor speed may be controlled via one of the following three methods (see page 4 and 5 for detail instructions): 1. On-Board Speed Potentiometer 2. External Speed Potentiometer – (Recommend 10k – 10 Turn Precision Potentiometer) 3. External Control Voltage For technical application assistance: 800-577-8685 ext. 3539 • +1-828-837-5115 Moog Components Group • www.moog.com/components...
- Page 4 Note: Pot #1 = Potentiometer Terminal #1, Pot #2 = Potentiometer #2, Pot #3 = Potentiometer Terminal #3 Figure 1 Connection Diagram for External Speed Potentiometer For technical application assistance: 800-577-8685 ext. 3539 • +1-828-837-5115 Moog Components Group • www.moog.com/components...
- Page 5 5. Set up the speed control for the controller (depending upon which method of speed control is used - see Speed Control). 6. After completion of step #5, speed control is now active. 7. Set the maximum current via the on-board speed potentiometer (current). For technical application assistance: 800-577-8685 ext. 3539 • +1-828-837-5115 Specifications and information are subject to change without prior notice. © 2014 Moog Inc. MS3124, rev. 1 11/16 Moog Components Group • www.moog.com/components...
