Table 2-8. ELVIS Function Generator Configuration Switch (SW13)
Channel
AMP_LEFT_IN
AMP_RIGHT_IN
1 Bold typeface denotes the default settings.

LEDs and Push Buttons

This section describes the on-board LEDs and push buttons. The LED
and push button locations are shown in
Figure 2-6. LED and Push Button Locations
ADSP-21369 EZ-KIT Lite Evaluation System Manual
www.BDTIC.com/ADI
ADSP-21369 EZ-KIT Lite Hardware Reference
Switch Position
5 (OFF)
6 (OFF)
Audio Signal
FUNCT_OUT
FUNCT_OUT
Figure 2-6.
2-15
