creates the new session and connects to the EZ-KIT Lite. Once
connected, the main window's title is changed to include the ses-
sion name set in step 6.
To disconnect from a session, click the disconnect button
or select Session–>Disconnect from Target.
To delete a session, select Session –> Session List. Select the ses-
sion name from the list and click Delete. Click OK.

Evaluation License Restrictions

The ADSP-21369 EZ-KIT Lite installation is part of the VisualDSP++
installation. The EZ-KIT Lite is a licensed product that offers an unre-
stricted evaluation license for the first 90 days. Once the initial
unrestricted 90-day evaluation license expires:
1. VisualDSP++ allows a connection to the ADSP-21369 EZ-KIT
Lite via the USB Debug Agent interface only. Connections to sim-
ulators and emulation products are no longer allowed.
2. The linker restricts a user program to 7281 words of memory for
code space with no restrictions for data space.
Refer to the VisualDSP++ Installation Quick Reference Card for details.

External Memory

The EZ-KIT Lite contains four types of memory: parallel flash (1 MB),
SPI flash (2 Mbit), SRAM (512 Kbit), and SDRAM (128 Mbit). Flash
memories can store user-specific boot code and allow the board to run as a
stand-alone unit. For more information on how to select a boot device for
the processor, see
page 2-10.
ADSP-21369 EZ-KIT Lite Evaluation System Manual
www.BDTIC.com/ADI
"Boot Mode and Clock Ratio Select Switch (SW2)" on
Using ADSP-21369 EZ-KIT Lite
1-7
