Elvis Interface - Analog Devices ADSP-21369 EZ-KIT Lite Manual

A
TP13
VDDINT_SHUNT VDDINT
1
R143
0
0603
R144
11.0K
0603
C187
0.1UF
0603
DSP CORE CURRENT
2
NOTE:
R143 needs to be replaced with 0.1 OHM resistor,
if this circuit is to work for ELVIS power measurements.
TP14
VDDEXT_SHUNT VDDEXT
U6
3
IN+
2
IN-
8
RG+
1
RG-
AD623ARMZ
USOIC8
R149
3
0.1
0603 R150
25.5K
0603
C189
0.1UF
0603
4
A
B
A5V
R146
90.9K
0603
U5
U33
3 7 2
IN+ V+
R145
2 4 10.0K 6
IN- V-
0603
8 6 3
RG+ OUT
AD820ARZ
1 5
RG- REF SOIC8
AD623ARMZ C192 R142
USOIC8 0.01UF 10.0K
0402 0603 A5V
C190
0.01UF
0402
AGND
AGND
A5V
R151
90.9K
0603
U34
7 2
V+
R147
4 10.0K 6
V- ACH1+
0603
6 3
OUT
AD820ARZ
5
SOIC8
REF
C188 R148
0.01UF 10.0K
0402 0603
A5V
C191
0.01UF
AGND 0402
AGND
DSP IO CURRENT
B
1
ELVIS Select Jumper
ACH0+
ELVIS_5V
ELVIS_PWR
P6 DNP
JP3
1 2 A01
+15_P_1
A02
+15_P_2
IDC2X1 A03
+5_P_1
A04
+5_P_2
A05
+5_P_3
ELVIS Voltage Selection Jumper
A06
GND5
A07
RS_P[6]
A08
RS_P[4]
A09
RS_P2 RS_P[2]
A10
RS_P0 RS_P[0]
A11
GND7
A12
KEY2
A13
KEY4
A14
WS_P[6]_1
A15
WS_P4_1 WS_P[4]_1
A16
WS_P2_1 WS_P[2]_1
A17
WS_P0_1 WS_P[0]_1
A18
GND9
A19
ELVIS_5V ID6
A20
ID4
A21
ID2
A22
ID0
A23
GND11
A24
NC1
A25
AS_P[6]_1
A26
AS_P[4]_1
A27
AS_P[2]_1
A28
AS_P[0]_1
A29
PB_PRES_1
A30
UPDATE
A31
CONVERT
A32
SCANCLK
A33
ELVIS_TRIGGER_S TRIG1_2
A34
GATE1_1
A35
GPCTR0_SOURCE
A36
GPCTR0_OUT_1
A37
GND13
A38
VH_1
A39
AIGND2
A40
ACH7_1
A41
ACH6_1
A42
ACH5_1
A43
ACH4+ ACH4
A44
AIGND4
A45
ACH3+ ACH3
A46
ACH2
A47
ACH1+ ACH1
A48
ACH0+ ACH0
A49
AISENSE_1
A50
KEY6
A51
KEY8
A52
NC4
A53
FG_SYNC_1
A54
FUNC_OUT FG_SIG_1
A55
GND14
A56
NC5
A57
ZL_1
A58
ZH_1
A59
NC8
A60
DAC0 DAC0_2
A61
GND17
A62
VDCA_1
PCI32B
AGND
ELVIS CONNECTOR
NI ELVIS ID 31 (0001 1111)
www.BDTIC.com/ADI
C
JP2
DAIP4_ELVIS_TRIG
2
ELVIS_SELECT
IDC2X1
P11
1 2
3 4
IDC2X2
AIN_LEFT
AIN_RIGHT
B01
DAC0
-15_P_1
B02
-15_P_2
B03
GND1 DAC1
B04
GND2
B05
GND3 FUNC_OUT
B06
GND4
B07
RS_P[7]
B08
RS_P[5]
B09
RS_P[3] RS_P3
B10
RS_P[1] RS_P1
B11
GND6
B12
KEY1
B13
KEY3
B14
WS_P[7]_1
B15
WS_P[5]_1 WS_P5_1
B16
WS_P[3]_1 WS_P3_1
B17
WS_P[1]_1 WS_P1_1
B18
GND8
B19
ID7
B20
ID5 ELVIS_5V
B21
ID3
B22
ID1
B23
GND10
B24
AS_P[7]_1
B25
AS_P[5]_1
B26
AS_P[3]_1 AS_P3_1
B27
AS_P[1]_1
B28
+5V2
B29
WFTRIG
B30
STARTSCAN ACH3+
B31
EXTSRTOBE
B32
TRIG2
B33
SOURCE1_1
B34
GPCRT1_OUT
B35
GPCTR0_GATE
B36
FREQ_OUT
B37
GND12
B38
VL_1 ACH4+
B39
AIGND1
B40
ACH15_1
B41
ACH14_1
B42
ACH13_1
B43
ACH12
B44
AIGND3
B45
ACH11
B46
ACH10
B47
ACH9
B48
ACH8
B49
NC2
B50
KEY5
B51
KEY7
B52
NC3
B53
FM_1
B54
AM_1
B55
+5V3
B56
GND15
B57
NC6
B58
ZM_1
B59
NC7
B60
DAC1_2 DAC1
B61
GND16
B62
VDCB_1
ANALOG
DEVICES
Title
Size Board No.
C
Date 5-28-2009_15:27
C
D
JP4
1 2
ELVIS_TRIGGER_S
IDC2X1
ELVIS Programmable Flag Jumper
SW13
ON
1 12
AIN_AMP_LEFT
2 11
AIN_AMP_RIGHT
3 10
4 9
5 8
6 7
DIP6
SWT017
Function Generator Switch
SW1
1 16
AIN_AMP_LEFT
2 15
AIN_AMP_RIGHT
3 14
AOUT1_LEFT
4 13
AOUT1_RIGHT
5 12
6 11
7 10
8 9
DIP8
SWT016
Oscilloscope Select Switch
20 Cotton Road
Nashua, NH 03063
PH: 1-800-ANALOGD
ADSP-21369 EZ-KIT Lite

ELVIS INTERFACE

Rev
A0196-2005
2.2
Sheet 10 of 13
