3. Plug the provided power supply into
Visually verify that the green power LED (
that the red reset LED (
off, and, finally,
4. Connect one end of the USB cable to an available full speed USB
port on your PC and the other end to
EZ-KIT Lite board.

Installation and Session Startup

For correct operation, install the software and hardware in the
order presented in the VisualDSP++ Installation Quick Reference
Card.
1. Verify that the yellow USB monitor LED (
USB connector) is lit. This signifies that the board is communicat-
ing properly with the host PC and is ready to run VisualDSP++.
2. If you are running VisualDSP++ for the first time, navigate to the
VisualDSP++ environment via the Start –> Programs menu. The
main window appears. Note that VisualDSP++ does not connect to
any session. Skip the rest of this step to step 3.
If you have run VisualDSP++ previously, the last opened session
appears on the screen. You can override the default behavior and
force VisualDSP++ to start a new session by pressing and holding
down the Ctrl key while starting VisualDSP++. Do not release the
Ctrl key until the Session Wizard appears on the screen. Go to
step 4.
ADSP-21369 EZ-KIT Lite Evaluation System Manual
www.BDTIC.com/ADI
Using ADSP-21369 EZ-KIT Lite
) goes on for a moment and then goes
LED10
through
LED1 LED8
on the EZ-KIT Lite board.
J4
) is on. Also verify
LED9
are sequentially blinking.
on the ADSP-21369
ZJ1
, located near the
ZLED3
