Serial peripheral interface (SPI) flash memory
2 Mbit
• Analog audio interface
AD1835A codec
4 x 2 RCA phono jack for 4 channels of stereo output
2 x 1 RCA phono jack for 1 channel of stereo input
3.5 mm headphone jack for 1 channel stereo output
• Digital audio interface
RCA phono jack output
RCA phono jack input
• Universal asynchronous receiver/transmitter (UART)
ADM3202 RS-232 driver/receiver
DB9 female connector
• National Instruments Educational Laboratory Virtual Instrumen-
tation Suite (ELVIS) Interface
LabVIEW™-based virtual instruments
Multifunction data acquisition device
Bench-top workstation and prototype board
• LEDs
Eleven LEDs: one power (green), one board reset (red), one
USB monitor (amber), and eight general-purpose (amber)
ADSP-21369 EZ-KIT Lite Evaluation System Manual
