Connectors
The power connector supplies DC power to the EZ-KIT Lite board.
Table 2-14 shows the power supply specifications.
Table 2-14. Power Supply Specifications
Terminal
Center pin
Outer ring
RS-232 Connector (J6)
Part Description
DB9, female, right angle
Cable DB9M to DB9F 6 feet

S/PDIF Coax Connectors (J7 and J8)

Part Description
Coaxial
Two-channel RCA interconnect
cable

DPI Header (P3)

The DPI connector (
from of a .1" spacing header. When using the header to access the DPI
pins of the processor, ensure that signals, which normally drive the DPI
pins, are disabled. For more information, see
2-24
www.BDTIC.com/ADI
Connection
+7 VDC@2.14A
GND
Manufacturer
AMP/TYCO
Mating Cable
DIGI-KEY
Manufacturer
SWITCHCRAFT
Mating Cable
MONSTER CABLE
) provides access to all of the DPI signals in the
P3
ADSP-21369 EZ-KIT Lite Evaluation System Manual
Part Number
5745781-4
45-0308-0000-ND
Part Number
PJRAN1X1U01
BI100-1M
"DPI Interface" on page 2-5.
