Evaluation License Restrictions

Evaluation License Restrictions
The ADSP-BF561 EZ-KIT Lite installation is part of the VisualDSP++
installation. The EZ-KIT Lite is a licensed product that offers an unre-
stricted evaluation license for the first 90 days. Once the initial
unrestricted 90-day evaluation license expires:
• VisualDSP++ allows a connection to the ADSP-BF561 EZ-KIT
Lite via the USB Debug Agent interface only. Connections to sim-
ulators and emulation products are no longer allowed.
• The linker restricts a users program to 41 KB of internal memory
for code space with no restrictions for data space.
The EZ-KIT Lite hardware must be connected and powered up to
use VisualDSP++ with a valid evaluation or permanent license.
Refer to the VisualDSP++ Installation Quick Reference Card for details.

External Memory

EZ-KIT Lite board includes two types of external memory, 64-MB
SDRAM and 8-MB flash.
devices. The complete configuration of the ADSP-BF561 processor inter-
nal SRAM is detailed in
Table 1-1. EZ-KIT Lite External Memory Map
Start Address End Address Description
0x00000000 0x3FFFFFF
0x20000000 0x207FFFFF
All other locations
1-6
Table 1-1 shows the memory map of these
Figure 1-2.
SDRAM Bank 0; see
ASYNC Memory Bank 0; see
Not used
ADSP-BF561 EZ-KIT Lite Evaluation System Manual
"External Memory" on page 1-6
"External Memory" on page 1-6.
