creates the new session and connects to the EZ-KIT Lite. Once
connected, the main window's title is changed to include the ses-
sion name set in step 6
To disconnect from a session, click the disconnect button
or select Session–>Disconnect from Target.
To delete a session, select Session –> Session List. Select the ses-
sion name from the list and click Delete. Click OK.

Evaluation License Restrictions

The ADSP-21375 EZ-KIT Lite installation is part of the VisualDSP++
installation. The EZ-KIT Lite is a licensed product that offers an unre-
stricted evaluation license for the first 90 days. Once the initial
unrestricted 90-day evaluation license expires:
1. VisualDSP++ allows a connection to the ADSP-21375 EZ-KIT
Lite via the USB Debug Agent interface only. Connections to sim-
ulators and emulation products are no longer allowed.
2. The linker restricts a user's program to 10922 words of internal
memory for code space with no restrictions for data space.
Refer to the VisualDSP++ Installation Quick Reference Card for details.

External Memory

The EZ-KIT Lite contains three types of memory: parallel flash (1 MB),
SPI flash (2 Mbit), and SDRAM (128 Mbit). The flash memories can
store user-specific boot code, allowing the board to run as a stand-alone
unit. For more information about selecting the boot device for the proces-
sor, see "Boot Mode and Clock Ratio Select Switch (SW2)" on page
ADSP-21375 EZ-KIT Lite Evaluation System Manual
Using ADSP-21375 EZ-KIT Lite
2-10.
