How to use this manual

Symbols used

Reference Documentation

- I.2 -
This Operation Manual is divided into 4 Chapters and an Appendix.
Chapter 1 – Overview describes the main features, components and the operation
principle of MULTIFEEDER devices.
Chapter 2 – Technical Data and Installation gives the necessary instructions to
install the devices with the KTF/PW4 or PFU/64S power supply.
Chapter 3 – Operation gives a detailed description of the necessary operations to
setup and program the MULTIFEEDER devices according to the application
needs.
Chapter 4 – Troubleshooting and Maintenance provides a quick guide to solving
the main failures of MULTIFEEDER devices.
Appendix – provides the necessary information for the firmware upgrade on the
interface/power supply PFU/64FS boards.
Highlights notes, warnings and subjects to which the attention of the reader
should be directed.
Indicates a particularly sensitive situation which could have an effect
on the safety or proper operation of the system.
P1.2
TENSION ERROR
All the items concerning the device programming menus, within this
manual, are always show in
For operating details about the programming/analysis and monitoring systems
available for MULTIFEEDER device management, please refer to the following
BTSR manuals.
SMART MATRIX FEEDER Manual – Rev. 3.0 – Ed. 05/2012
Rolling FEEDER/MED Manual – Rev. 3.0 – Ed. 05/2012
PC-LINK KTF Studio Manual – Rev. 1.0 – Ed. 03/2005
PC-LINK NEMO PROFILER Manual – Rev. 1.0 – Ed. 03/2012
PFU/64FS SYSTEM Manual
SMART MATRIX PFU Manual
MULTIFEEDER
letters.
CAPITAL BOLD
Introduction
