Technical Data and Installation
PFU/64FS configuration
The PFU/64FS interface/power supply board can be configured to operate in 5 different modes, according to
the configuration used (Note 1)
•
Software Mode
• Hardware 0 Mode
•
Hardware 1 Mode
• Emulation 0 Mode
•
Emulation 1 Mode
Each operating mode has different characteristics and a different I/O signal assignment on the board
connectors.
The selected mode is indicated by the number of
(see next page)
LED symbols
= LED OFF
= LED ON
= LED blinking
Note 1: to modify/upgrade the configuration, please refer to the appendix "Firmware upgrade through SD-CARD or
USB key".
: NEXT CYCLE, START/STOP, ZPX, PRX LEDs
blinks on
MULTIFEEDER - 2.13 -
