btsr MULTIFEEDER Operating Manual page 32

SMART connector
This connector makes available a serial line which can be used for the direct communication with all the
Feeder devices connected by means of SMART MATRIX PFU terminal or PC LINK software.
SMART RxTx+
SMART RxTx-
AUX RxTx+
AUX RxTx-
MC/PC connector
In Hardware configuration this connector is currently not used.
EXC connector
This connector makes available the I/O Hardware signals to control the Feeder devices connected to Groups
1-2-3-4.
INC GRP 1
DEC GRP 1
INC GRP 2
DEC GRP 2
INC GRP 3
DEC GRP 3
INC GRP 4
DEC GRP4
EXC +
EXC -
MC/SYNC connector
This connector makes available the auxiliary signals interfacing with the machine.
EX STOP 1
EX STOP 2
EXC RF+
EXC RF-
INPUT POLARITY
- 2.20 -
Serial line reserved for SMART MATRIX PFU terminal connection (communication
speed 345600 Bps)
Serial line reserved for communication with PC LINK BTSR software
(communication speed 115200 Bps)
INC signals for Feeder devices connected to group GRP 1
DEC signals for Feeder devices connected to group GRP 1
INC signals for Feeder devices connected to group GRP 2
DEC signals for Feeder devices connected to group GRP 2
INC signals for Feeder devices connected to group GRP 3
DEC signals for Feeder devices connected to group GRP 3
INC signals for Feeder devices connected to group GRP 4
DEC signals for Feeder devices connected to group GRP 4
EXCLUSION SIGNAL OF ALL THE FEEDERS CONNECTED
Alarm signal (to the machine stop input)
AUXILIARY STOP signal
Positive OPTO-INSULATED signal for Rollingfeeder exclusion
Negative OPTO-INSULATED signal for Rollingfeeder exclusion
Input lines PULL/UP and PULL/DOWN activation
MULTIFEEDER
Technical Data and Installation
