Introduction

How to use this manual

Symbols used

IS3
SM-DIN Within this manual, the SM-DIN/WARP interface modules, will be generically
Congratulations for choosing a BTSR product.
With our SMART WARP yarn control system, you got an innovative, unique
solution, which offers you multiple advantages concerning the quality control of
your production.
SMART WARP has been designed for applications on large warping machines
that use in continuous mode a large number of yarns (up to 2000) during the entire
working cycle.
The system is capable of self-learning the number of yarns used by the textile
machine during a sample cycle, indicating any type of errors detected during the
subsequent production cycles (broken or missing yarns, uncut or not correctly used
yarns, threading or pick-up errors, etc.).
SMART WARP, combined with yarn control sensors IS3F-485, represents a
complete and effective machine control system.
This Operation Manual is divided into 4 Chapters
Chapter 1 – Overview describes the main features, components and the operation
principle of the system.
Chapter 2 – Technical Data and Installation gives the necessary instructions to
install the system correctly.
Chapter 3 – Operation gives a detailed description of the necessary operations to
setup and program the system according to the application needs.
Chapter 4 – Troubleshooting and Maintenance provides a quick guide to solving
the main technical faults of the system.
Highlights notes, warnings and subjects to which the attention of the reader
!
should be directed.
Indicates a particularly sensitive situation which could have an
effect on the safety or proper operation of the system.
Within this manual, the IS3F-485 sensors used on SMART WARP application,
will be generically indicated as IS3.
indicated as SM-DIN.
SMART WARP
INTRODUCTION INTRODUCTION
INTRODUCTION INTRODUCTION
