Operation

P4 Programming Level

The P4 programming level allows you to select the various device operating
modes:
1) Language used to display menus and messages;
2) Application on which the device will be used;
3) Yarn type: either normal or elastic;
4) INC-DEC and STOP signal polarity (Normally Open or Normally Closed
contact).
5) Operating Mode
to select the P4 level.
to continue.
LANGUAGE SELECTION
P4.1
This function allows you to select the language used to display menu items,
messages and errors.
or to scroll forward/backward the list of available languages:
– –
ITALIANO ENGLISH
to confirm the language indicated on display and return to the beginning of P4
menu.
APPLICATION SELECTION
P4.2
This function allows you to choose one of the pre-defined applications.
The behavior of MULTIFEEDER device (e.g. reaction to INC/DEC pulses) will
depend on the chosen application.
or to scroll forward/backward the list of available applications:
–
SOCKS REVERSE SOCKS
–
REVERSE KNIT FLAT KNIT
to confirm the application shown on display and move to the next parameter.
MULTIFEEDER
LFA m/min
–
FRANCAIS ESPANOL
– –
MEDICAL SOCKS
– –
SMALL LOOM
ADVANCED
– –
DEUTSCH JAPANESE
–
PANTYHOSE SEAMLESS
–
SEWING RASCHEL
MENU P4
-
CHINESE
– –
KNIT
- 3-17 -
