btsr MULTIFEEDER Operating Manual page 56

- 3-18 -
ELASTIC
P4.3
This function allows you to set the yarn characteristics.
or to choose between
options.
to confirm the application shown on display and move to the next parameter.
* The mode allows a better handling of bare elastic yarns.
ELASTIC
SIGNAL POLARITY
P4.4
This function allows you to setup the polarity of
to toggle the
INC
to toggle the
STOP
to confirm the options shown on display and move to the next parameter.
MOTOR-D
P4.5
This function allows you to select the MULTIFEEDER device motor rotation
direction.
Keep the button pressed for 3 seconds to change the motor rotation direction
(CW = clockwise rotation; CCW = counter-clockwise rotation)
to confirm the options shown on display and move to the next parameter.
UNICO
P4.6
This function allows you to either enable or disable the functionality of UNICO
accessory.
or to select either
to confirm the options shown on display and move to the next parameter.
MULTIFEEDER
*
ELASTIC ELASTIC
- signal between
DEC NO
signal between or
NO
(function enabled) or
AUTO
2, 3,
ELASTIC ALL YARN
- and signals.
INC DEC STOP
or .
NC
.
NC
(function disabled).
OFF
Operation
