Insert a Flat Head Hex Screw through one of the two Screw
26.
Holes on the Grab Handle and into one of the two Screw
Holes on the Crossbar. The Flat Head Hex Screw location
will determine the height of the Grab Handle.
Repeat steps 25 - 26 to install the second Flat Head Hex
27.
Screw.
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Grab Handle Mounting Heights
29
