Dual-Monitor Wall Mount
ARMDUALWALL
FR: Guide de l'utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l'uso - it.startech.com
For the latest information, technical specifications, and support for
this product, please visit www.StarTech.com/ARMDUALWALL.
Manual Revision: 12/04/2018
*actual product may vary from photos
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StarTech.com ARMDUALWALL
Summary of Contents for StarTech.com ARMDUALWALL
- Page 1 Dual-Monitor Wall Mount ARMDUALWALL *actual product may vary from photos FR: Guide de l’utilisateur - fr.startech.com DE: Bedienungsanleitung - de.startech.com ES: Guía del usuario - es.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com IT: Guida per l’uso - it.startech.com For the latest information, technical specifications, and support for this product, please visit www.StarTech.com/ARMDUALWALL.
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
- Page 3 Warning statements Mensagens de aviso Make sure that you assemble this product according to the instructions. Certifique-se de que monta este produto de acordo com as instruções. Read the entire manual and make sure that you understand the instructions before you start to Leia todo o manual e certifique-se de que entende as instruções antes de começar a montar e a assemble and use this product.
-
Page 4: Table Of Contents
Attach the mounting arms ........................9 Attach the crossbar ..........................12 Mount the monitors ..........................14 Attach the VESA monitor mounts to the crossbar ................ 15 Adjust the ARMDUALWALL ........................16 Organize your cables ..........................17 Technical support ...................18 Warranty information ................18... -
Page 5: Product Diagram
Product diagram VESA monitor mount VESA monitor mount Crossbar Wall plate Mounting arm Cable-management clip Mounting arm Product dimensions ±15° 70 mm 360° rotation Instruction manual... -
Page 6: Technical Specifications
Technical specifications Type of measurement Measurement 75x75 100x100 VESA 5 kg (11 lb.) per monitor mount RATED LOAD 3600 ROTATION -150 to +150 TILT Between 381 mm and 610 mm (15 in. and 24 in.) SCREEN 1800 SWIVEL Instruction manual... -
Page 7: Package Contents
Package contents Wall plate Plastic covers Qty: One Qty: Two Mounting arms VESA monitor mounts Qty: Two Qty: Two Crossbar Crossbar cap Qty: One Qty: One Instruction manual... - Page 8 M4x12 mm screws M4x30 mm screws Qty: Eight Qty: Eight Spacers Cable-management clips Qty: Eight Qty: Two Hex key Mounting-arm retainer Qty: One Qty: One Instruction manual...
- Page 9 M8x16 mm screws Mounting-arm washers Qty: Three Qty: Three Mounting-arm caps Wall-plate retainer Qty: Two Qty: One Level M8x60 mm screws Qty: One Qty: Four Instruction manual...
-
Page 10: Requirements
Qty: One Qty: One Requirements • Two monitors that are compatible with one of the VESA mounting hole patterns that ARMDUALWALL supports • A Phillips type screwdriver Requirements are subject to change. For the latest requirements, please visit www.StarTech.com/ARMDUALWALL. Instruction manual... -
Page 11: Installation
Note: It may require two people to attach the wall plate to the wall. 1. Position the wall plate where you want to hang the ARMDUALWALL and use the provided level to make sure that the wall plate is vertical. (figure 1) - Page 12 3. Use the four holes in the wall plate as a template to mark the wall. 4. Follow the appropriate steps for the type of wall that you’re attaching the wall plate to and attach the wall plate to the wall. (figure 2) figure 2 Wall plate 5.
-
Page 13: Attach The Mounting Arms
Attach the mounting arms 1. Place one of the mounting arms over the projection on the wall plate. (figure 4) figure 4 Mounting arm Wall plate Projection 2. Place a mounting-arm washer into the joint in the mounting arm. 3. Place the wall-plate retainer onto the mounting-arm washer. 4. - Page 14 6. Snap one of the mounting-arm caps over the joint in the mounting arm. (figure 6) figure 6 Mounting-arm cap Mounting arm Wall plate 7. Place the second mounting arm over the projection in the other mounting arm. (figure 7) figure 7 Mounting arm Projection...
- Page 15 8. Place a mounting-arm washer into the joint in the mounting arm. 9. Place the mounting-arm retainer over the mounting-arm washer. 10. Insert an M8x16 mm screw through the mounting-arm retainer, mounting-arm washer, and into the mounting arm. (figure 8) 11.
-
Page 16: Attach The Crossbar
Attach the crossbar 1. Place the crossbar over the projection on the mounting arm. (figure 10) figure 10 Crossbar Projection Mounting arm 2. Place the crossbar retainer into the crossbar. 3. Place a mounting-arm washer onto the crossbar retainer. 4. Insert an M8x16 mm screw through the washer, crossbar retainer, and into the crossbar. - Page 17 4. Snap the crossbar cap into the crossbar. (figure 12) figure 12 Crossbar cap Crossbar Instruction manual...
-
Page 18: Mount The Monitors
Mount the monitors To accommodate different monitor designs, the ARMDUALWALL comes with two sets of screws of different lengths and diameters, and spacers. 1. To select the combination of mounting hardware to attach the VESA monitor mounts to the monitors, complete the following: •... -
Page 19: Attach The Vesa Monitor Mounts To The Crossbar
Attach the VESA monitor mounts to the crossbar Warning! Make sure that the weight of the monitors doesn’t exceed the weight capacity of this product. If you exceed the weight capacity, you might experience personal injury or damage to the product. This product can support up to 5 kg (11 lb.) per monitor mount. -
Page 20: Adjust The Armdualwall
Adjust the ARMDUALWALL 1. To adjust the position of your monitors, do any of the following: • To move the monitors up or down in small increments, turn the knobs at the top of each of the VESA monitor mounts. (figure 16) •... -
Page 21: Organize Your Cables
Organize your cables 1. Attach the cable-management clips to the crossbar. 2. Route the cables along the crossbar. 3. Snap the cables into the cable-management clips. (figure 18) figure 18 Crossbar Cable Cable-management clip Instruction manual... -
Page 22: Technical Support
Limitation of liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 23 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
