Slim Desk Mount Articulating Monitor Arm
with Cable Management
ARMSLIM
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 07/23/2018
*actual product may vary from photos
Advertisement
Table of Contents
Related Manuals for StarTech.com ARMSLIM
Summary of Contents for StarTech.com ARMSLIM
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 07/23/2018...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Introduction ....................1 ........................1 Packaging Contents Product Overview ..................2 Installation ....................3 Desk / Grommet Mounting ........................3 Attaching the Display ..........................7 Adjusting Monitor Mount Resistance ....................9 Specifications ..................11 Technical Support ..................12 Warranty Information ................12 Instruction Manual... -
Page 4: Introduction
Introduction Packaging Contents Monitor Arm 2-in-1 Desk/Grommet Thumb Screws Qty: 1 Clamp Qty: 4 Qty: 1 6mm Allen Wrench 3mm Allen Wrench Qty: 1 Qty: 1 Instruction Manual... -
Page 5: Product Overview
Product Overview <7 kg 147 mm Instruction Manual... -
Page 6: Installation
Installation Warning! It is the installer’s responsibility to ensure that the combined weight of all components does not exceed the maximum 7 kg (15.43 lbs) weight capacity of the mounting arm. Desk / Grommet Mounting The Monitor Arm can be clamped to a desk / table, or mounted through a grommet hole. - Page 7 2. Slide the Monitor Arm (1) onto the base and tighten the set screw on the back of the base, using the 3mm Allen Wrench (5). Instruction Manual...
- Page 8 Grommet Mount 1. To convert the 2-in-1 Clamp to a Grommet Mount, turn the Clamp upside-down and remove the 4 screws that join the clamp to the base of the monitor arm, using the 3mm Allen Wrench (5). 2. Remove the Phillips Screw and the 2 Washers from the top of the Pressure Plate and then slide the Hand Screw out of the clamp.
- Page 9 4. Place the base of the Monitor Arm (1) over the grommet hole and thread the Hand Screw from below until secure. Ensure that the Pressure Plate is making full contact with the desk surface. Note: The Grommet Clamp can support a desk / table thickness from ¾ - 1.97 in (20 –...
-
Page 10: Attaching The Display
5. Slide the Monitor Arm (1) onto the base and tighten the set screw on the back of the base, using the 3mm Allen Wrench (5). Attaching the Display 1. Carefully place your display face down on a protective surface to access the mounting points. - Page 11 3. Attach the display to the Mount Bracket using the 4 Thumb Screws (3). Warning: Do not over-tighten the screws and stop immediately if you encounter resistance to avoid damage to your display. Ensure that all screws being used are the same length and thread type.
-
Page 12: Adjusting Monitor Mount Resistance
Adjusting Monitor Mount Resistance Warning: Forced movement of the Mount Bracket without loosening the screws may damage the product or the mounted display. Always support your display from underneath when making any adjustments to the LCD Arm or Mount Bracket to avoid damage to the display. Note: For all adjustments outlined below, turning the screw clockwise will increase the resistance, while turning the screw counter-clockwise will decrease resistance. - Page 13 To increase / decrease the tilt resistance, adjust the set screw located on the side of the Monitor Mount joint, using the 6mm Allen Wrench (4). To increase / decrease swivel resistance, adjust the set screws located beneath the swivel points using a Phillips screwdriver, or on the base of the arm using the 3mm Allen Wrench (5).
-
Page 14: Specifications
Specifications Weight Capacity 15.43 lbs (7 kg) Max Display Size 26” VESA Compatibility 75x75 mm and 100x100 mm Maximum Mounting Surface Thickness 3.94 in (100 mm) Instruction Manual... -
Page 15: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 16 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
