DGS-3212SR Switch CLI Reference
config access_profile
ip − Specifies that the switch will look into the IP
Parameters
fields in each packet.
vlan <vlan_name 32> − − Specifies that the
access profile will apply to only to this VLAN.
source_ip <ipaddr> − Specifies that the access
profile will apply to only packets with this source IP
address.
destination_id <value 0-255> − Specifies that the
access profile will apply to only packets with this
destination IP address.
dscp <value 0-63> − Specifies that the access
profile will apply only to packets that have this
value in their Type-of-Service (DiffServ code
point, DSCP) field in their IP packet header.
icmp − Specifies that the switch will examine the
Internet Control Message Protocol (ICMP) field
within each packet.
type <value 0-65535> − Specifies that the
access profile will apply to this ICMP type
value.
code <value 0-255> − Specifies that the
access profile will apply to this ICMP code.
igmp − Specifies that the switch will examine the
Internet Group Management Protocol (IGMP) field
within each packet.
type <value 0-255> − Specifies that the
access profile will apply to packets that have
this IGMP type value.
tcp − Specifies that the switch will exmamine the
Transmission Control Protocol (TCP) field within
each packet.
Access Control List (ACL) Commands
config access_profile
src_port <value 0-65535> − Specifies that the
Parameters
access profile will apply only to packets that
have this TCP source port in their TCP header.
dst_port <value 0-65535> − Specifies that the
access profile will apply only to packets that
have this TCP destination port in their TCP
header.
udp − Specifies that the switch will examine the
Universal Datagram Protocol (UDP) field in each
packet.
src_port <value 0-65535> − Specifies that the
access profile will apply only to packets that have
this UDP source port in their header.
dst_port <value 0-65535> − Specifies that the
access profile will apply only to packets that have
this UDP destination port in their header
protocol_id <value 0-255> − Specifies that the
switch will examine the Protocol field in each
packet and if this field contains the value
entered here, apply the following rules.
user_define <hex 0x0-0xfffffff> − Specifies a
mask to be combined with the value found in the
frame header using a logical AND operaiton.
priority <value 0-7> − Specifies that the access
profile will apply to packets that contain this value
in their 802.1p priority field of their header.
