D-Link DGS-3212SR Command Line Interface Reference Manual page 139

DGS-3212SR Switch CLI Reference
config 802.1x auth_parameter
Used to configure the 802.1x Authentication
Purpose
parameters on a range of ports. The default
parameter will return all ports in the specified
range to their default 802.1x settings.
config 802.1x auth_parameter ports
Syntax
[<portlist>|all] [default|{direction
[both|in]|port_control
[force_unauth|auto|force_auth]| quiet_period
<sec 0-65535>| max_req <value 1-
10>|reauth_period <sec 1-
65535>|enable_reauth [enable|disable]}]
The config 802.1x auth_parameter command
Description
is used to configure the 802.1x Authentication
parameters on a range of ports. The default
parameter will return all ports in the specified
range to their default 802.1x settings.
<portlist> − Specifies a range of ports. The port
Parameters
list is specified by listing the lowest switch
number and the beginning port number on that
switch, separated by a colon. Then highest
switch number, and the highest port number of
the range (also separated by a colon) are
specified. The beginning and end of the port list
range are separated by a dash. For example,
1:3 would specify switch number 1, port 3. 2:4
specifies switch number 2, port 4. 1:3-2:4
specifies all of the ports between switch 1, port
3 and switch 2, port 4 − in numerical order.
all − Specifies all of the ports on the switch.
default − Returns all of the ports in the specified
range to their 802.1x default settings.
direction [both|in] − Determins whether a
controlled port blocks communication in both the
recieving and transmitting directions, or just the
802.1X COMMANDS
receiving direction.
port_control − Configures the administrative
control over the authentication process for the
range of ports.
force_auth − Forces the Authenticator for the
port to become authorized. Network access is
allowed.
auto − Allows the port's status to reflect the
outcome of the authentication process.
force_unauth − Forces the Authenticator for the
port to become unauthorized. Network access
will be blocked.
quiet_period <sec 0-65535> − Configures the
time interval between authentication failure and
the start of a new authenticaiton attempt.
max_req <value 1-10> − Configures the number
of times to retry sending packets to a supplicant
(user).
reauth_period <sec 1-65535> − Configures the
time interval between successive re-
authentications.
enable_reauth [enable|disable] − Determines
whether or not the switch will re-authenticate.
Enable causes re-authentication of users at the
time interval specified in the Re-authentication
Period field, above.
Restrictions Only administrator-level users can issue this
command.
133
