Chapter 2: Jumpers and Connectors

Power Button Pin Header

Connector type: 1x2 2-pin header, 2.54mm pitch
Connector location: JPWRBTN1
2 1
Pin Definition
1 GND
2 FP_PWRBTN_N
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.

Bypass LED Pin Header

Connector type: 1x2 2-pin header, 2.54mm pitch
Connector location: J9, J10, J11 and J12
2 1
J9
Pin Definition
1 VCC3
2 BYPASS_LED_S4
J11
Pin Definition
1 VCC3
2 BYPASS_LED_S3
J12
Pin Definition
1 VCC3
2 BYPASS_LED_S2
J12
Pin Definition
1 VCC3
2 BYPASS_LED_S1
