Chapter 2: Jumpers and Connectors

PCIe Golden Finger (For LAN Module)

Connector location: GFM1
B49 B12 B11
Pin Definition
A1 RST_X8_GF_N
A2 LPC_AD0
A3 LPC_AD1
A4 LPC_AD2
A5 LPC_AD3
A6 LPC_FRAME_N
A7 VCC3_3
A8 RST_X8_GF_N
A9 VCC3_3
A10 VCC3_3
A11 ALL_PWRGD
A12 SYS_FAN
A13 VCC3_3
A14 VCC3_3
A15 CK_SLOT1_DP
A16 CK_SLOT1_DN
A17 VCC3_3
A18 CLK_GF_33M
A19 VCC3_3
A20 AUX_TEMP
A21 CPU-
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
B1
Pin Definition
B1 PCIE3_SEL1
B2 PCIE3_SEL2
B3 PCIE3_SEL3
B4 VCC3_3
B5 SMB_CLK_MAIN
B6 SMB_DATA_MAIN
B7 VCC3_3
B8 VCC3_3
B9 GF_SUSCLK
B10 VCC3_3
B11 SMB_ALERT_N
B12 USB_OC45#
B13 WAKE_N
B14 3VSB
B15 3VSB
B16 3VSB
B17 USB_4P
B18 USB_4N
B19 VCC3_3
B20 VCC3_3
B21 VCC3_3
Pin Definition
A22 ATX_PWROK_A1
A23 ATX_PWROK_A1
A24 GND
A25 PEG_TXP0
A26 PEG_TXN0
A27 GND
A28 PEG_TXP1
A29 PEG_TXN1
A30 GND
A31 PEG_TXP2
A32 PEG_TXN2
A33 GND
A34 PEG_TXP3
A35 PEG_TXN3
A36 GND
A37 PEG_TXP4
A38 PEG_TXN4
A39 GND
A40 PEG_TXP5
A41 PEG_TXN5
A42 GND
A43 PEG_TXP6
A44 PEG_TXN6
A45 GND
A46 PEG_TXP7
A47 PEG_TXN7
A48 GND
A49 GND
24
Pin Definition
B22 ATX_PWROK_A1
B23 ATX_PWROK_A1
B24 GND
B25 PEG_RXP0
B26 PEG_RXN0
B27 GND
B28 PEG_RXP1
B29 PEG_RXN1
B30 GND
B31 PEG_RXP2
B32 PEG_RXN2
B33 GND
B34 PEG_RXP3
B35 PEG_RXN3
B36 GND
B37 PEG_RXP4
B38 PEG_RXN4
B39 GND
B40 PEG_RXP5
B41 PEG_RXN5
B42 GND
B43 PEG_RXP6
B44 PEG_RXN6
B45 GND
B46 PEG_RXP7
B47 PEG_RXN7
B48 GND
B49 GND
