Chapter 2: Jumpers and Connectors

Jumpers

RTC Clear

Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP2
1 3
Pin Function
1-2 Normal
2-3 Clear CMOS
Pin Definition
1 VCCRTC
2 RTC_RST#
3 GND
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.

ATX/AT Select

Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP1
1 3
Pin Function
1-2 ATX Mode
2-3 AT Mode
Pin Definition
1 NC
2 AT_ATX_SELECT
3 GND
8
