Chapter 4: BIOS Setup
Network Configuration
This section is used to configure the network settings.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Advanced
Network Configuration
Power_ON ByPass Mode [ALL Disabled]
Power_OFF ByPass Mode [ALL Disabled]
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Power_ON ByPass Mode
Enables or disables the LAN module bypass mode after the system powers
on.
Power_OFF ByPass Mode
Enables or disables the LAN module bypass mode after the system powers
off.
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
SATA Configuration
This section is used to configure the SATA drives.
Switch all ByPass Mode to
Enable/Disable after power on.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
SATA Controller(s)
Enables or disables the SATA controller.
SATA Mode Selection
Configures the SATA as IDE or AHCI mode.
IDE
AHCI
44
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Advanced
SATA Controller(s) [Enabled]
SATA Mode Selection [AHCI]
SATA Test Mode [Disabled]
Aggressive LPM Suppor [Enabled]
SATA Controller Speed [Default]
Empty
Serial ATA Port 0
Software Preserve Unknown
Port 0 [Enabled]
Hot Plug [Disabled]
[Disabled]
External SATA
SATA Device Type [Hard Disk Drive]
Spin Up Device [Disabled]
Serial ATA Port 1 Empty
Software Preserve Unknown
Port 1 [Enabled]
Hot Plug [Disabled]
External SATA [Disabled]
SATA Device Type [Hard Disk Drive]
Spin Up Device [Disabled]
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
This option configures the Serial ATA drives as Parallel ATA
physical storage device.
This option configures the Serial ATA drives to use AHCI
(Advanced Host Controller Interface). AHCI allows the storage
driver to enable the advanced Serial ATA features which will
increase storage performance.
▲
Enable or Disable SATA Port
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
▼
