Chapter 2: Jumpers and Connectors

PCIe x8 Slot

Connector type: PCIe x8 Slot
Connector location: PCIE1
A1 A11 A12 A49
B1 B11 B12 B49
Pin Definition
A1 PRSNT1
A2 VCC12
A3 VCC12
A4 GND
A5 NC
A6 NC
A7 NC
A8 NC
A9 VCC3
A10 VCC3
A11 RST_X8_SLOT_N
A12 GND
A13 CK_SLOT2_DP
A14 CK_SLOT2_DN
A15 GND
A16 PEG_SRXP0
A17 PEG_SRXN0
A18 GND
A19 NC
A20 GND
A21 PEG_SRXP1
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
B1 VCC12
B2 VCC12
B3 VCC12
B4 GND
B5 SLOT_SMC
B6 SLOT_SMD
B7 GND
B8 VCC3
B9 NC
B10 3VSB
B11 PCIE_WAKE_L
B12 NC
B13 GND
B14 PEG_STXP0
B15 PEG_STXN0
B16 GND
B17 PCIe_PRSNT
B18 GND
B19 PEG_STXP1
B20 PEG_STXN1
B21 GND
Pin Definition
A22 PEG_SRXN1
A23 GND
A24 GND
A25 PEG_SRXP2
A26 PEG_SRXN2
A27 GND
A28 GND
A29 PEG_SRXP3
A30 PEG_SRXN3
A31 GND
A32 NC
A33 NC
A34 GND
A35 PEG_SRXP4
A36 PEG_SRXN4
A37 GND
A38 GND
A39 PEG_SRXP5
A40 PEG_SRXN5
A41 GND
A42 GND
A43 PEG_SRXP6
A44 PEG_SRXN6
A45 GND
A46 GND
A47 PEG_SRXP7
A48 PEG_SRXN7
A49 GND
23
Pin Definition
B22 GND
B23 PEG_STXP2
B24 PEG_STXN2
B25 GND
B26 GND
B27 PEG_STXP3
B28 PEG_STXN3
B29 GND
B30 NC
B31 PCIe_PRSNT
B32 GND
B33 PEG_STXP4
B34 PEG_STXN4
B35 GND
B36 GND
B37 PEG_STXP5
B38 PEG_STXN5
B39 GND
B40 GND
B41 PEG_STXP6
B42 PEG_STXN6
B43 GND
B44 GND
B45 PEG_STXP7
B46 PEG_STXN7
B47 GND
B48 PCIe_PRSNT
B49 GND
