Chapter 4: BIOS Setup
H/W Monitor
This section is used to monitor hardware status such as temperature, fan
speed and voltages.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Advanced
PC Health Status
System Temperature : +32 C
LAN Module Temperature : N/A
CPU Temperature : +31 C
LAN Module Fan Speed : N/A
Smart FAN1 Speed : N/A
Smart FAN2 Speed : 2824 RPM
PCH Fan Speed : N/A
: N/A
Fan1 Speed
: +1.768 V
VCORE
DRAM Voltage : +1.520 V
VCC5 : +5.080 V
VCC12 : +12.288 V
VCC3 : +3.216 V
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
System Temperature
Detects and displays the current system temperature.
CPU Temperature
Detects and displays the current CPU temperature.
LAN Module Fan Speed
Detects and displays the fan speed of the LAN module.
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
Smart Fan1 Speed and Smart Fan2 Speed
Detects and displays the fan speed of smart fan1 and smart fan2.
PCH Fan Speed
Detects and displays the PCH fan speed.
Fan1 Speed
Detects and displays the Fan1 speed.
VCORE
Detects and displays the VCore voltage.
DRAM Voltage
Detects and displays the DRAM voltage.
VCC5
→←: Select Screen
↑↓: Select Item
Detects and displays 5V voltage.
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
VCC12
F3: Optimized Defaults
F4: Save & Exit
Detects and displays 12V voltage.
ESC: Exit
VCC3
Detects and displays 3.3V voltage.
