Function keys of the STAND BY Display
The function keys on the right hand side of the display allow the operator to access the numerous
menus imbedded within the Sentry Plus Series instrument software. Familiarize yourself with
these menus prior to programming a test. Figure 2-1 illustrates the STAND BY display and lists
the functions that can be accessed by pressing the [F1] through [F4] keys.
M1
STEP 1/1
1.250kV
15.00mA
3.0s
Instrument
STAND BY
Status
F1
PROGRAM
MORE..
Insert
Delete
NEXT
STEP: 1-10
MODE: AC/DC/IR/GC/PA
Voltage
High Limit
Test Time
Low Limit
ARC Limit
Ramp Time
Dwell Time
Fall Time
In Rush Current
Page 32 of 85
"STAND BY" or "Power-Up" Display
AC
LOW
ARC
RAMP
FALL
RMT
LOCK
F2
PRESET
AC-V Freq.
Soft AGC.
WV Auto Range
IR Auto Range
GFI
FAIL Restart
(DC, IR)
(DC)
Figure 2-1: STAND BY Function Key Menus
: OFF
PROGRAM
: OFF
: OFF
PRESET
: OFF
MENU
MORE..
OFST
ERR
F3
F4
MENU
MORE
Memory
View Test Steps (Tabular Format)
Store
Offset
Recall
Delete
System
Contrast
Buzzer Volume
EN 50191
DC 50V AGC
Option
Multi-Link
Calibration
(Need password to enter)
Key Lock
(Need password to enter)
Change Password
(Need password to enter)
Error Log
About
Manufacturer
Software version
Function of F1 - F4 Keys
F1
To enter programming mode.
F2
To view/change preset (initial) settings.
To view/change: memory, system, option,
F3
cal., key lock, pw, error & about.
To view the programmed test setups and
F4
access offset function.
Operation
