1.3.2 Rear Panel Controls and Connectors

Figure 1-3 illustrates the controls and connectors on the rear panel of the Sentry Plus Series
AC/DC/IR Hipot Tester. Table 1-2 identifies them with description and function.
WARNING: FOR CONTINUED PROTECTION
! AGAINST FIRE HAZARD, REPLACE ONLY WITH
THE SAME TYPE AND RATING OF FUSE AS
SPECIFIED FOR THE LINE VOLTAGE BEING
UTILIZED.
CAUTION: NO OPERATOR SERVICEABLE PARTS
!
INSIDE. REFER SERVICING TO QUALIFIED
PERSONNEL.
POLLUTION DEGREE 2
INSTALLATION CATEGORY II
VOLTAGE SELECTOR
1
MODEL NO.
SERIAL NO.
HIGH VOLTAGE
Max 5kVAC/6kVDC
HV OUTPUT
10
Figure 1-3: Rear Panel Sentry Plus Series Instrument
Table 1-2: Sentry Plus Series Rear Panel Controls & Connectors
Reference # Name
Figure 1-3
1 VOLTAGE
SELECTOR
2 Remote
3 CONT CHK OPT.
4 TUV CE
5 Remote
6 Fan
7 Ground
8 AC Line Input
9 RTN/LOW
10 HV OUTPUT
Introduction
2
1
6
90V - 110V ~ CONT. CHECK OPTION
3.15AT
250V
108V - 132V ~
198V - 242V ~
1.6AT
250V
216V - 250V ~
100V/120V/220V/240V~
50/60Hz 300W MAX
RTN/LOW
9 8
Type
2 Red 2-position
Slide Switches
Silver 9-pin
D-Type Connector
Black banana plug
Sticker
Black 5-screw
Terminal Strip
SF11580AT
115V 50/60Hz 0.10A
Silver Banana Plug
Black 3-wire inlet
module & fuse holder
Blue Banana Socket
White Custom
Banana Socket
3 4 5
5
9
START
RESET
COM
INTER
LOCK
7
Function
Select Voltage Level corresponding to AC Source
90V – 110V: 3.15A 250V Slow Blow
110V – 130V: 3.15A 250V Slow Blow
200V – 240V: 1.6A 250V Slow Blow
220V – 250V: 1.6A 250V Slow Blow
Remote Connection: Inputs: Start, Reset
Outputs: Pass, Fail, Under Test
Connection for Ground Continuity Check
Instrument Safety Agency Listing
Remote Connection: Start, Reset, Com, Interlock
Cool Unit: T≥50°C = ON, T<45°C = OFF
Instrument Chassis Ground Connection
Connection to AC power source
Fuse Drawer: 3.15A 250V or 1.6A 250V (see #1)
RTN: Low voltage reference terminal
LOW: Common ground reference terminal
Rear panel High Voltage (Potential) Terminal
6
o
FAN 50 C AUTO ON/OFF
