Specifications
1
Specifications
1.4
Specifications
Specifications
Power
3HP Electric
Material Capacities
Min width 0" or 3" if not clamped between larger material
Max width – 56" or 72" (optional)
Min thickness ½"
Max thickness 8"
Min length22"
Max length – 13' or longer with 5' bed extensions
Min depth of cut 1/64"
Max depth of cut – 1/8"
Cutter Head
Knives – Five 4-sided carbide (15 x 15 x 2.5mm – R150)
Sanding Head – 7" orbital with hook and loop paper (Velcro)
Speed – Variable up to 5,500 RPM
Feed Motor Motor, 1/6hp 90RPM 3phase 19:1 gear Continuous Duty
Feed Speed I'll have to get this info.
Machine Dimensions & Weight
Length – 182"
Width – 65"
Table Height – 30" – 33"
Machine Height 71" Max
Weight Will get later.
Shipment Weight- Will get later.
Machine Standards & Requirements
Electrical requirements – 1-Phase, 220V, 30 A
Dust collection port diameter 3 ½" OD of dust head.
WMdoc082019
1-5
